| Brand Name: | Wellgain |
| Model Number: | WG-VEN-5000 |
| MOQ: | 1 Set |
| Price: | USD 8-20 / Square Meter |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 50,000 SQM per Month |
The Wellgain WG-VEN-5000 Venlo Type Multi Span Greenhouse represents the pinnacle of commercial horticultural infrastructure. Originating from Dutch greenhouse engineering traditions, the Venlo design maximizes light transmission through its distinctive narrow-pane roof structure while providing exceptional structural integrity through aluminum alloy gutters and hot-dip galvanized steel columns.
This greenhouse style is the preferred choice for growers of high-value crops including orchids, anthuriums, premium tomatoes, and propagation nurseries where every percentage point of light transmission directly impacts revenue. The aluminum gutter system minimizes shadow casting compared to traditional steel gutters, while the continuous roof ventilation provides superior natural airflow management.
The WG-VEN-5000 is fully compatible with advanced climate control systems including high-pressure fogging, CO2 enrichment, supplemental LED lighting, and fully automated environmental computers. Its modular Venlo bay design enables efficient space utilization and easy future expansion.
| Parameter | Specification |
|---|---|
| Structure Type | Venlo Style Multi Span |
| Column Material | Hot-dip Galvanized Steel |
| Gutter Material | Aluminum Alloy (Extruded) |
| Span Width | 9.6m / 12.0m (3x3.2m or 3x4.0m bays) |
| Bay Distance | 4.0m |
| Gutter Height | 4.0m - 6.0m |
| Ridge Height | 5.5m - 7.5m |
| Roof Ventilation | Continuous Roof Vent (Rack & Pinion) |
| Light Transmission | Up to 92% (glass), 88% (PC sheet) |
| Wind Load | 0.60 KN/m² |
| Snow Load | 0.35 KN/m² |
| Covering Options | Glass (4mm tempered) / PC Sheet (8mm) |
